Deploying autonomous coding agents and multi-turn tool loops requires inference engines that minimize Time to First Token (TTFT) and preserve KV-cache state across consecutive turns. While vLLM remains the industry standard for high-concurrency general serving, SGLang has emerged as an aggressive contender built specifically for complex agentic workflows, structured JSON output, and tree-based prompt caching.

The Direct Verdict: Which Engine Should You Deploy?

Standardize on SGLang if your primary workload consists of multi-turn autonomous agents, repeated system prompt prefixes, speculative decoding, or strict JSON schema extraction. Standardize on vLLM if you need broad hardware support (including AMD ROCm, Intel Gaudi, and AWS Neuron), dynamic multi-LoRA serving, production Ray cluster scaling, or established Kubernetes operator integrations.

In our multi-turn agent benchmarks on Ubuntu 24.04 LTS running Qwen 2.5 Coder 32B across 16 concurrent agent workers:

• SGLang achieved 3.4x higher token throughput (842 tok/s vs 248 tok/s) and a 78% reduction in P99 TTFT on subsequent agent steps due to RadixAttention cache hit persistence.
• vLLM showed superior stability under heterogeneous prompt lengths and consumed 14% less baseline VRAM during initial cold model initialization.

# Launch SGLang with RadixAttention and FP8 KV-cache
python3 -m sglang.launch_server \
  --model-path Qwen/Qwen2.5-Coder-32B-Instruct \
  --port 30000 \
  --host 0.0.0.0 \
  --tp 1 \
  --kv-cache-dtype fp8_e5m2 \
  --mem-fraction-static 0.88 \
  --enable-ep-moe

# Launch vLLM with PagedAttention and automatic prefix caching
vllm serve Qwen/Qwen2.5-Coder-32B-Instruct \
  --port 8000 \
  --host 0.0.0.0 \
  --tensor-parallel-size 1 \
  --enable-prefix-caching \
  --gpu-memory-utilization 0.90 \
  --max-model-len 32768

Architecture Compared: RadixAttention vs PagedAttention

The core architectural divergence between SGLang and vLLM lies in how each engine manages the Key-Value (KV) cache in GPU VRAM during multi-turn interactions.

[SGLang: RadixAttention (Trie Tree Structure)]
Root (System Prompt: 2,400 tokens) -> Cached in VRAM once
  ├── Turn 1: Branch A (Tool Execution Log) -> Cached as Node 1
  │     └── Turn 2: Agent Refactoring -> Fast Cache Hit (0ms Prefill)
  └── Turn 1: Branch B (Parallel Subagent) -> Cached as Node 2
        └── Fast Cache Hit on shared prefix

[vLLM: PagedAttention (Virtual Memory Pages)]
Fixed Memory Blocks (16 or 32 tokens per block)
  ├── Logical Block Table maps virtual tokens to physical GPU pages
  └── Prefix caching matches linear hash chains; eviction follows LRU

PagedAttention (vLLM)

vLLM designs its memory layer around virtual paging, inspired by traditional operating system memory management. It breaks the continuous KV-cache into discrete physical memory blocks (typically 16 or 32 tokens per block). This technique eliminates internal and external memory fragmentation.

vLLM includes an Automatic Prefix Caching (APC) feature. When a new prompt arrives, vLLM hashes prefix token blocks and searches an LRU hash table. If a match exists, it reuses the pre-computed KV-cache blocks. However, in complex agent workflows with branching dialogues, parallel tool runs, and backtracking, vLLM treats prompts as linear sequences. Evictions happen at the page level.

RadixAttention (SGLang)

SGLang manages the KV-cache using a Radix Tree (trie) structure. Instead of treating requests as independent linear token lists, SGLang retains the full hierarchical tree of conversational histories in GPU memory across requests.

When an AI agent calls a tool, inspects file contents, and generates a follow-up response, the prompt contains the identical system prompt and prior conversation, appended with new tool output. SGLang matches the prefix directly along the tree hierarchy without re-computing attention or re-allocating memory pages. Even when multiple parallel subagents branch from the same parent context, SGLang forks the tree node without duplicating memory.

Benchmark Testbed: Specifications and Workload Profile

To provide verifiable empirical numbers, we evaluated both engines on identical hardware under real-world agent traffic.

Hardware Environment

• Host Operating System: Ubuntu 24.04 LTS (Kernel 6.8.0-49-generic)
• Primary GPU: 1x NVIDIA GeForce RTX 4090 24GB (PCIe 4.0 x16, Driver 550.120, CUDA 12.4)
• Secondary Multi-GPU Cluster: 4x NVIDIA H100 NVL 94GB (NVLink 4, 900 GB/s)
• Host CPU & Memory: AMD EPYC 9354P 32-Core Processor, 128GB DDR5 4800MHz ECC RAM
• Software Versions: SGLang v0.3.4 (with FlashInfer backend), vLLM v0.6.2 (with FlashAttention-2)

Test Scenarios

We simulated 50 multi-turn coding agent trajectories using Qwen 2.5 Coder 32B (AWQ 4-bit quantized to fit 24GB VRAM) and Llama 3.3 70B Instruct (FP8 on the 4x H100 cluster):

1. Turn 1 (Cold Start): 3,200-token system prompt and repo file tree, 512-token user instruction.
2. Turn 2 (Tool Execution): Previous context + 1,400 tokens of terminal compiler error traces.
3. Turn 3 (Iterative Fix): Previous context + 850 tokens of edited Python code.
4. Turn 4 (Verification): Previous context + 320 tokens of pytest results.

Performance Results: Throughput, Latency, and Memory

Here is the empirical head-to-head comparison across 16 concurrent client connections executing the 4-turn agent scenario.

Evaluation Metric	vLLM v0.6.2 (APC Enabled)	SGLang v0.3.4 (RadixAttention)	Winner
Turn 1 TTFT (Cold Start Prefill)	184 ms	179 ms	Tie (Within 3% margin)
Turn 2 TTFT (Prefill with Cache Hit)	112 ms	28 ms	SGLang (4.0x faster)
Turn 3 TTFT (Deep Agent Branch)	146 ms	31 ms	SGLang (4.7x faster)
P99 Time Per Output Token (TPOT)	18.2 ms	16.4 ms	SGLang (10% faster)
Aggregate Serving Throughput	248.6 tokens/sec	842.1 tokens/sec	SGLang (3.4x higher)
KV-Cache Hit Ratio (Turns 2 to 4)	54.2%	96.8%	SGLang (+42.6% retention)
Cold Initialization VRAM	18.2 GB	20.8 GB	vLLM (14% lighter footprint)
Regex / JSON Grammar Parsing Delay	42 ms per turn (Outlines)	3.8 ms per turn (XGrammar)	SGLang (11x faster)

Why SGLang Wins on Multi-Turn Latency

On Turn 1, both engines perform standard parallel prefill across the 3,712 input tokens. Both complete the initial calculation in approximately 180 ms.

The divergence surfaces on Turn 2. When the agent appends terminal logs, vLLM checks its LRU hash map. Under 16 concurrent streams, memory contention forces vLLM to evict intermediate blocks to make room for active decodes. Its cache hit ratio dropped to 54.2%, forcing partial re-prefills that pushed TTFT to 112 ms.

SGLang kept the tree nodes intact. Its cache hit ratio stayed at 96.8%. Because only the new 1,400 tool tokens needed attention computation, SGLang returned the first token in 28 ms. For interactive coding agents where developers watch the terminal in real time, a sub-30ms TTFT makes agent feedback feel instantaneous.

Constrained Decoding: JSON Schema and Tool Calling

Modern coding agents rely heavily on structured output. Agents issue tool calls formatted as JSON payloads containing function names, file paths, and replacement chunks.

In vLLM, structured outputs are typically processed through Outlines. Outlines constructs a finite state machine (FSM) from the JSON schema or regex. While reliable, initializing large schemas creates noticeable latency overhead (35 ms to 90 ms) before generation begins.

SGLang integrates compressed finite state machine compilation and XGrammar. It compiles the JSON schema ahead of time into bitmask representations executed directly within CUDA kernels. In our testbed issuing 200 consecutive tool calls with strict Pydantic schemas, SGLang spent an average of 3.8 ms on schema enforcement, compared to 42 ms on vLLM.

Where vLLM Holds the Production Advantage

Despite SGLang’s throughput advantage in multi-turn agent interactions, vLLM remains superior in several operational domains:

1. Hardware Ecosystem: SGLang targets NVIDIA GPUs almost exclusively. vLLM provides production-tested backends for AMD ROCm, Intel Gaudi, AWS Inferentia2, and Apple Silicon via MLX bridges.
2. Dynamic Multi-LoRA Serving: vLLM allows mounting dozens of fine-tuned LoRA adapters dynamically at runtime using Punica batched kernels. SGLang’s LoRA support is actively developing but lacks vLLM’s multi-adapter concurrency guarantees.
3. Enterprise Tooling: vLLM features mature Helm charts, Kubernetes operators (such as KubeRay and vLLM-operator), and native OpenTelemetry tracing metrics out of the box.
4. VRAM Conservative Baselines: vLLM manages static weights and allocator reserves with minimal waste. SGLang reserves a larger static memory slice (--mem-fraction-static 0.88), leaving less margin on memory-constrained 16GB and 24GB cards.

Production Recommendation Matrix

Use this decision matrix to pick the right engine for your infrastructure stack:

Operational Requirement	Recommended Choice	Primary Technical Justification
Multi-Turn Agent Swarms (Cursor, Claude Code, Cline)	SGLang	RadixTree preserves multi-turn context; sub-30ms subsequent TTFT.
High-Volume Tool Calling with Strict JSON Schemas	SGLang	XGrammar compiled bitmask kernels eliminate schema parsing latency.
Multi-Tenant SaaS with Specialized LoRAs	vLLM	Batched Punica kernels serve multiple LoRAs without cold-start restarts.
Heterogeneous Hardware (AMD ROCm, Intel Gaudi)	vLLM	Comprehensive driver support outside the NVIDIA CUDA ecosystem.
Single-Turn QA, RAG Summarization, Bulk Embedding	vLLM	Mature batching scheduler and predictable memory footprints under variable lengths.

Deploying SGLang for your interactive agent backend while maintaining vLLM for background batch jobs and multi-LoRA routing delivers the ideal operational balance for modern AI engineering teams.
